9 Layer Co Extruded 100um Frozen Food PE Packaging Film

9 Layer Co Extruded 100um Frozen Food PE Packaging Film
9 Layer Co Extruded 100um Frozen Food PE Packaging Film 9 Layer Co Extruded 100um Frozen Food PE Packaging Film 9 Layer Co Extruded 100um Frozen Food PE Packaging Film 9 Layer Co Extruded 100um Frozen Food PE Packaging Film 9 Layer Co Extruded 100um Frozen Food PE Packaging Film

Large Image :  9 Layer Co Extruded 100um Frozen Food PE Packaging Film

Product Details:
Place of Origin: China
Brand Name: Tangke
Certification: FDA,BRC,ISO
Model Number: SP000P
Payment & Shipping Terms:
Minimum Order Quantity: negotiable
Price: negotiable
Packaging Details: 4 rolls one pallet, 20 pallets/20ft container
Delivery Time: 15-30 days producing
Payment Terms: negotiable
Supply Ability: 1500 Tons/monthly
Detailed Product Description
Type:: PE Film Usage:: Packaging Film
Hardness:: Soft Brand Name:: TangKe
Structure:: Symmetric/Asymmetric Feature:: Moisture Proof
Processing Type: Multiple Extrusion Place Of Origin:: Shanghai,China
Model Number:: SP000P Supply Ability:: 1200 Metric Ton/Metric Tons Per Month
Packaging Details:: Roll Packing+wooden Pallets,or Customized According To Customer's Requirements. Strcture: 7 / 9 Layer Co-extruded
Highlight:

100um PE Packaging Film

,

9 Layer pe plastic film

,

BRC PE Packaging Film

PE film roll BIB bag

◆ Product specifications:

Thickness Film width Roll diameter Roll mandrll inner dia
30-250μm 1300mm 300-1000mm 3"6"
Classic structure: PA/TIE/PE/TIE/EVOH/TIE/PA/TIE/PE
P.S.:Customers can choose other specifications.





◆ PA/EVOH/PE FILM-200um:



Performance require Units Technical Requirement Test standard Remark
Tensile Strength MD Mpa >70 GB/T 1040.3
TD >72
Elongation MD % >400 GB/T 1040.3
at Break TD >400
Heat Seal Strength N/15mm Film thickness Typical QB/T2358—1998
Values
100um >50
Haze % Film thickness Typical GB/T 2410-1980
Values
100um <12
C.O.F IN/OUT 0.4~0.8 GB/T10006—1998
WTR g/sq.m/day <5 GB/T 1037-200 Test
temperature
deviation
(-2~+2)℃
at38℃,100%R.H. ASTM F1249-2001
OTR cc/sq.m/day <2 GB/T 19789-2005
at23℃,0%R.H.ASTM D3985-1995
Remark The exact data will vary by gauge PApercentage composition EVOH percentage composition etc.





◆ Product discription:

Make formula with different PE raw material, laminate and print with base material like PET, aluminum

foil to pack products, widely used in mask bags , toothpaste material , Bag in box etc.



◆ Safety:
All the raw materials of our products go through certiificates of FDA,EC,REACH,and there is absolutely no additive during theprocess.The products go through certificats of QS in Australia,America,Japan and Europe and achieve food safety level.

◆ Storage conditions:

Please store at 5~35℃,keep dry,ventilated,and keep away from heat source at least 1 meter.




◆ Application:

Frozen vacuum packing

Processed meat fish sea food

Box in bag,such as sala,oil,and moisture packing

Bottom and lidding film for thermoforming film



9 Layer Co Extruded 100um Frozen Food PE Packaging Film 0

9 Layer Co Extruded 100um Frozen Food PE Packaging Film 19 Layer Co Extruded 100um Frozen Food PE Packaging Film 29 Layer Co Extruded 100um Frozen Food PE Packaging Film 39 Layer Co Extruded 100um Frozen Food PE Packaging Film 49 Layer Co Extruded 100um Frozen Food PE Packaging Film 5

                      Workshop display

9 Layer Co Extruded 100um Frozen Food PE Packaging Film 6

                        Transport packaging

9 Layer Co Extruded 100um Frozen Food PE Packaging Film 7

                     Certificate authentication

9 Layer Co Extruded 100um Frozen Food PE Packaging Film 8

                   Quality control judgment9 Layer Co Extruded 100um Frozen Food PE Packaging Film 9



FAQ:

1. You are the manufacturer or a trading company?



We are the manufacturer,and the quality can be guaranteed.was set up in 2006, covered an area of more than120 acres, first investment of USD 31 million



2. What kind of packaging can you do for us?



We can do various of kind packaging.The researh and development team is set to meet customized needs through flexible designing product structure and formulation according to different packing requirements.



3. What is your terms of packing?



Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.



4. What is your MOQ?



The MOQ is accoding to the size of the film you need,after you send us your size,we can caculate the MOQ for you.
